Style 144 Cutting Tip

One-piece, medium preheat acetylene cutting tip
8544402-01-1 shown

Style 144 one-piece cutting tip is designed for general-purpose, hand-cutting applications over a wide range of plate surface conditions. The tip has six preheat flames and can be used to cut material up to 7 inches (17.8 cm) in thickness with acetylene at speeds of 4 to 24 inches per minute (IPM) based on tip size and material thickness. For material over 7 inches (17.8 cm) in thickness, use style 164 cutting tip.

◂ scroll to see more ▸
Part Number Tip Size Drill Size Material Thickness Speed Oxygen Fuel
8544499-01-1 #00 69 (.029 in) 1/8 in (.3 cm) 21-24 IPM 30 PSIG/33 SCFH 1.5 PSIG/11 SCFH
8544400-01-1 #0 64 (.036 in) 1/4 in (6 cm) 20-23 IPM 30 PSIG/57 SCFH 2 PSIG/14 SCFH
8544401-01-1 #1 57 (.043 in) 1/2 in (1.3 cm) 18-21 IPM 30 PSIG/84 SCFH 3 PSIG/20 SCFH
8544402-01-1 #2 55 (.052 in) 9/10 in (2.5 cm) 14-17 IPM 40 PSIG/134 SCFH 3 PSIG/22 SCFH
8544403-01-1 #3 53 (.059 in) 2 in (5.1 cm) 11-14 IPM 45 PSIG/190 SCFH 3 PSIG/23 SCFH
8544404-01-1 #4 50 (.070 in) 2.5 in (6.3 cm) 8-11 IPM 50 PSIG/263 SCFH 3 PSIG/25 SCFH
8544405-01-1 #5 47 (.078 in) 4 in (10.2 cm) 7-10 IPM 45 PSIG/313 SCFH 4 PSIG/31 SCFH
8544406-01-1 #6 42 (.093 in) 5 in (12.7 cm) 5-7 IPM 50 PSIG/457 SCFH 5 PSIG/43 SCFH
8544406-01-1 #6 42 (.093 in) 6 in (15.2 cm) 5-6 IPM 55 PSIG/492 SCFH 5 PSIG/43 SCFH
8544406-01-1 #6 42 (.093 in) 7 in (17.8 cm) 4-5 IPM 65 PSIG/552 SCFH 5 PSIG/43 SCFH
◂ scroll to see more ▸
Document
Language
ID Number
Revision
Download
Style 164 and Style 144 Cutting Tips Catalog Page
English
IN164T
M
Download
Safe Practices in Oxy-Fuel Welding and Cutting Brochure
English
ADE0872AD
AD
