Active
580 Series UV/IR Flame Detector
Ultraviolet and Infrared flame detector for hydrocarbon and non-hydrocarbon fires
580 5005 shown
The 580 Series UV/IR Flame Detector utilizes dual-spectrum sensors to provide high-speed fire detection with exceptional false alarm immunity. By combining ultraviolet (UV) and infrared (IR) optical sensors, the device identifies both hydrocarbon and non-hydrocarbon fires within seconds and triggers an immediate response. Engineered for reliability, the 580 Series UV/IR Detector is resistant to the influences of direct or reflected sunlight and artificial lighting (florescent/halogen), electrical arcs and static discharges, and the radiation from arc welding (at distances exceeding 10 feet). Whether used as a standalone device or integrated into a networked safety system, the 580 Series UV/IR Flame Detector provides a dependable foundation for any fire monitoring solution.
- Dual spectrum technology utilizes UV and IR sensors for high-accuracy detection and superior false alarm immunity
- Broad range detection provides extensive area coverage
- Rapid alarm response enables quick safety and suppression actions
- Continuous internal health monitoring prevents undetected device failure
- Durable GRP fiberglass construction offers exceptional chemical, UV, and corrosion resistance
- Manual remote self-test facilitates functional sensor verification from a remote location without a test lamp
- Pressure compensating element (PCE) eliminates internal moisture build-up and protects internal seals from ambient pressure changes
- Configurable alarm relay accommodates specific site requirements
- Hazardous area certification supports use in harsh indoor and outdoor environments
- Flexible output options allow universal system integration through both 0–20 mA analog and SPDT relay signals
- Optional swivel mount (included) permits installation flexibility and precise directional positioning
